Applications
For water supply from wells or reservoirs.
For domestic use, for civil and industrial applications.
for garden use and irrigation. Operating conditions Maximum fluid temperature up to +35 ℃
Maximum sand content:0.3%
Maximum immersion depth: 100m.
Minimum well diameter:4″ Motor Rewindable motor
Full obturated screen motor
Three-phase: 380V-415V/50Hz
Single-phase: 220V-240V/50Hz
Equip with special start-up control box Internal diameter of outlet 1-1/4″1-1/2″ 2″
Special features available Other voltages.
Frequency 60Hz.
Other mechanical seal.
Equip with Auto-control box. Warranty:2 year (according to our general sales conditions).
