Applications
For water supply from wells or reservoirs.
For domestic use,for civil and industrial applications,for garden user and irrigation
|
|
Operating Conditions
Water temperature up to 35℃
Suction listuptoqm.
|
|
Motor
Three-phase:440V±10%(380-415V)
Single-phase:230V±10%(220-240V)
Control box with capacitor,on request.
|
|
Special features on request
Other voltages.
Frequency 60Hz.
Other mechanical seal.
Components Material:
Pump external casing
Delivery casing
Suction casing
Stage casing
Impeller
Wear ring
Motor external casing
Mechanical seal
Shaft
Bearing
|
Material:
AISI304ss
Cast iron G20 UNI5007
Cast rion G20 UNI5007
Plastic.PPO
AISI304ss
AISI304ss
Cast aluminum
Ceramic alumina,carbon,NBR
AISI304ss-C1045
NSK(Japan)
|
|
PERFORMANCE DATE 50Hz
| MODEL |
P2 |
DELIVERY n≈2850 1/min |
| 1-220V/240V |
3-380V/450V |
KW |
HP |
m3/h
I/min |
0 |
0.9 |
1.8 |
2.7 |
3.6 |
4.5 |
5.4 |
6.3 |
7.2 |
| 0 |
15 |
30 |
45 |
60 |
75 |
90 |
105 |
120 |
| SRM303 |
SR303 |
0.55 |
0.75 |
H(m) |
36 |
33 |
30 |
26 |
21 |
14 |
|
|
|
| SRM304 |
SR304 |
0.75 |
1 |
48 |
45 |
40 |
35 |
28 |
19 |
|
|
|
| SRM305 |
SR305 |
0.92 |
1.25 |
60 |
56 |
50 |
43 |
35 |
23 |
|
|
|
| SRM306 |
SR306 |
1.1 |
1.5 |
72 |
67 |
60 |
52 |
42 |
28 |
|
|
|
| SRM503 |
SR503 |
0.75 |
1 |
38 |
36 |
34 |
31 |
29 |
25 |
21 |
17 |
12 |
| SRM504 |
SR504 |
0.92 |
1.25 |
51 |
49 |
46 |
43 |
39 |
34 |
29 |
23 |
16 |
| SRM505 |
SR505 |
1.1 |
1.5 |
63 |
61 |
57 |
53 |
48 |
42 |
36 |
29 |
20 |
| SRM506 |
SR506 |
1.5 |
1 |
76 |
73 |
69 |
64 |
58 |
51 |
43 |
35 |
24 |
PERFORMANCE DATE 50Hz
| MODEL |
P2 |
DELIVERY n≈2850 1/min |
| 1-220V/240V |
KW |
HP |
m3/h
I/min |
0 |
1.8 |
3.6 |
5.4 |
7.2 |
9 |
10.8 |
12.6 |
14.4 |
16.2 |
| 0 |
30 |
60 |
90 |
120 |
150 |
180 |
210 |
240 |
270 |
| PSR352M |
0.75 |
1 |
H(m) |
29 |
28 |
26.4 |
24 |
20.2 |
15 |
9 |
|
|
|
| PSR353M |
1.1 |
1.5 |
45 |
42.8 |
40.4 |
36.8 |
30.8 |
23 |
13.2 |
|
|
|
| PSR354M |
1.5 |
2 |
59 |
56.8 |
53.8 |
45.6 |
40.5 |
30 |
17.8 |
|
|
|
| PSR355M |
2.2 |
3 |
72 |
67.3 |
62.6 |
57 |
48 |
35.5 |
20.4 |
|
|
|
| PSR452M |
1.5 |
2 |
32 |
30.4 |
29.5 |
28 |
26.4 |
24 |
20.4 |
16 |
11.4 |
|
| PSR453M |
2.2 |
3 |
47 |
45.4 |
43.7 |
41.6 |
39.2 |
36 |
31.5 |
26.2 |
19.6 |
12 |
| PSR454M |
3 |
4 |
62.4 |
60.5 |
58.5 |
56.3 |
53.7 |
49.8 |
43.4 |
35.2 |
25.6 |
15 |
| - |
3.4 |
4.5 |
74.5 |
73 |
71.4 |
69 |
65.7 |
61 |
53.4 |
43.5 |
31.8 |
18.6 |
|
