| FUNCTION AND FEATURE： The MVS 20/5F SINGLE VANE PUMP is designed for automatic use(sihgle phase version). The operating principle is that of pumps with a single vane impeller. This is mounted on the end of the drive shaft and enclosed in a large ring chamber, formed by the pump body and the base.The suction opening is in direct with the liquid to be pumped.The rotating impeller transmits kinetic energy to the liquid, which is centrifuged in the ring chamber,where part of the kinetic energy is transformed into pressure energy.The particular shape of the impeller optimizes efficiency.
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||
